[News] TSMC Rumored to Secure Tensor G6 Orders from Google with Its 2nm Process

On September 9, Indian tech blog PiunikaWeb cited a report from Tech & Leaks Zone, stating that rumors have hinting at Google’s preparation to exit Samsung Electronics’ wafer foundry business, Samsung Foundry, and switch to TSMC in 2025. The next two generations of Google’s custom Tensor processors are reportedly expected to use TSMC’s 3nm and 2nm processes, respectively.

As per the same report, Google’s Tensor G4 processor is being manufactured by Samsung Foundry using its 4nm process. However, the G4 offers only a slight upgrade compared to the Tensor G3 in the Pixel 8 smartphone, as the G4 continues to use Samsung’s older FO-PLP packaging technology instead of the newer FO-WLP packaging, which is more capable in preventing overheating.

On the other hand, Google’s Tensor G5, which will be used in the Pixel 10, is reportedly set to be manufactured by TSMC using the latest 3nm process and TSMC’s advanced InFO-POP packaging technology. The Tensor G6, which will support the Pixel 11 series, will also be produced by TSMC using 2nm process.

Notably, Apple had introduced an AI technical document in June, disclosed that two AI models supporting “Apple Intelligence” were trained in the cloud using Google’s custom-designed Tensor Processing Unit (TPU).

Per Google’s official website, the cost of using its most advanced TPU can be less than USD 2 per hour if reserved three years in advance. Google first introduced the TPU in 2015 for internal use, and it became available to the public in 2017.

Additionally, per a report from wccftech, Google’s ARM-based TPU v5p “Axion,” designed specifically for data centers, is also rumored to be manufactured using TSMC’s enhanced 3nm process, N3E.

Read more

• [News] Google’s Tensor G5 Reportedly Manufactured with TSMC’s 3nm and InFO-POP Packaging
• [News] Breaking Apple’s Monopoly – TSMC’s InFO Packaging Reportedly Adds Google Chips
