Disappointing financial results. A 15% layoff of its workforce. Restructuring and cost-reduction plans which may include the sale of FPGA unit Altera and freezing its USD 32 billion German fab project. Now, there seems to be more bad news on the way for Intel, as its advanced nodes, specifically 18A and 20A, reportedly run into trouble.

Broadcom Regards 18A Not Ready for High-volume Production

According to Reuters and The Verge, Broadcom’s initial tests with Intel’s 18A (1.8nm-class) process did not meet expectations, creating additional pressure on the semiconductor giant’s efforts to catch up with TSMC in the foundry sector. The reports note that Broadcom tested Intel’s 18A by producing wafers with typical design patterns. However, its engineers and executives were said to be disappointed with the results, regarding the process as “not ready for high-volume production.”

A Broadcom spokesperson informed Reuters that the company has not yet completed its evaluation of Intel’s 18A, indicating that the assessment is still in progress.

The 18A node plays a crucial role in Intel’s roadmap, as it has been working on the process for years, targeting to begin mass production next year, with major clients including Microsoft, according to the Verge.

However, another report from Tom’s Hardware also suggests that a defect density below 0.5 defects per square centimeter is typically seen as a positive outcome, which Intel may have already accomplished. Citing CEO Pat Gelsinger’s previous remarks, the report notes that Intel is now below 0.4 d0 defect density, which can be considered a healthy process.

20 A Cancelled: Not a Bad Idea for Cost-reduction?

Another latest bad news, though, is that Intel announced that it will no longer use its own 20A process for the upcoming Arrow Lake processors aimed at the consumer market. In its own words, the Arrow Lake processor family will be built primarily using external partners and packaged by Intel Foundry.

The unexpected move, according to Intel, is made in order to focus resources on Intel 18A, helping the company to optimize its engineering investments.

The strategy might not be a bad idea amid Intel’s crisis, as the bypass of the 20A process altogether can help avoiding the significant capital expenditures needed to scale the node to full production, a report by Tom’s Hardware notes. By sidestepping the typically high costs associated with ramping up a new and advanced node like 20A, the company will likely make progress toward its cost-cutting objectives. The order of Arrow Lake, though, might possibly go to TSMC, the report indicates.

Read more

• [News] AMD Could Emerge as a Prospective Buyer for Intel’s Potential Sale of Altera
• [News] Intel Reportedly Mulls to Sell FPGA Unit Altera and Freeze USD 32 Billion German Project amid Crisis

(Photo credit: Intel)

While surrounded by concerns raised by the USD 1.6 billion net loss in Q2 and the large-scale layoff plan, Intel has finally shared some good news. It announced on August 6^th that its next-gen 18A process has achieved a major milestone, and will start production in 2025.

The semiconductor giant states that the milestone has been achieved less than two quarters after tape-out, and confirms that two of its next-gen products, Panther Lake (AI PC client processor) and Clearwater Forest (server processor), will be fabricated with the node. The first external customer is expected to tape out on Intel 18A in the first half of next year, according to its press release.

The company also gives an advance notice on the progress of the aforementioned two processors. According to Intel, Clearwater Forest will mark the industry’s first mass-produced, high-performance solution combining RibbonFET, PowerVia, and Foveros Direct 3D for higher density and power handling. In addition, Panther Lake DDR memory performance is already running at target frequency.

Earlier in July, Intel released the 18A Process Design Kit (PDK) 1.0, design tools that enable foundry customers to harness the capabilities of RibbonFET gate-all-around transistor architecture and PowerVia backside power delivery in their designs on Intel 18A.

It is worth noting that Intel’s 18A is the company’s second fabrication technology, following 20A, to employ RibbonFET and PowerVia. A report by Tom’s Hardware notes that compared to Intel’s 2nm-class node, 18A offers an optimized RibbonFET design and additional enhancements, resulting in a 10% increase in performance per watt, which makes it especially fitted for data center-class products that require significant power.

The report also notes that Intel 18A is a process that Intel Foundry’s potential customers are very interested in, as some believed it to be more competitive than TSMC’s 3nm and 2nm-class offerings, which are expected to be available between 2024 and 2025.

On the other hand, TSMC, the global foundry leader, said earlier in the earnings call that it’s 2nm (N2) node is progressing well, and will begin mass production in 2025. The company is also on track to launch the N2P and A16 processes in the second half of 2026.

Read more

• [News] NVIDIA’s Backup Plan? Intel Reportedly Secures Packaging Orders from the AI Giant
• [News] Intel’s Earnings Fall Short, Cutting Over 15% of Workforce

(Photo credit: Intel)
