In mid-August, TSMC had signed a contract with panel manufacturer Innolux to purchase its plant and facilities located in southern Taiwan, eyeing to further expand its advanced packaging capacity. According to a report by China Times, the fab, designated as the AP8 facility, is expected to start production in the second half of 2025.

More importantly, the fab will not only provide foundry services but also the eagerly needed capacity for advanced 3D Chip on Wafer on Substrate (CoWoS) IC packaging services, the report notes.

The move will be critical for TSMC to meet the surging demand for the advanced packaging capacity for AI servers, according to the report. Its future capacity will reportedly be nine times that of AP6, TSMC’s advanced packaging fab in Zhunan.

Outbidding Micron, TSMC secured the plant with a transaction value of NTD 17.14 billion, which is much lower than the rumored market price of over NTD 20 billion. Citing sources from the supply chain, the report suggests that the main reason TSMC acquired Innolux’s fab was to bypass the time-consuming environmental assessment process.

Unlike the advanced packaging fab in Chiayi, central Taiwan, which has to be started from scratch, the newly-acquired facility only requires internal modifications. Within a year, TSMC can finish the job of equipment installation, and begin the production afterwards.

Sources cited by the report note that orders for related equipment manufacturing are already underway, with deliveries expected starting in April next year. While the process of trial production may take an additional quarter, the AP8 facility is expected to start production in the second half of 2025.

During an investor conference in mid-April, TSMC Chairman C.C. Wei stated that he anticipates the company’s CoWoS capacity to more than double in both 2024 and 2025. He noted later in July that TSMC targets to reach the balance between supply and demand by 2026.

According to analysts cited by the report, TSMC’s CoWoS capacity, though still remains in short supply, could exceed 32,000 wafers per month by the end of this year. With the additional outsourced capacity, the total CoWoS capacity may approach 40,000 wafers per month. By the end of 2025, TSMC’s CoWoS monthly capacity is projected to reach around 70,000 wafers.

Citing remarks by Jun He, TSMC Vice President of Operations and Advanced Packaging Technology and Service, TSMC’s CoWoS capacity is expected to achieve a compound annual growth rate (CAGR) of over 50% from 2022 to 2026. The foundry giant will also accelerate its pace on constructing fabs, shortening the typical 3-to-5-year timeline to within 2 years to meet customer demand.

Read more

• [News] TSMC Took Another Step in Advanced Process Expansion

(Photo credit: TSMC)

According to a report from Commercial Times citing sources, it’s revealed that NVIDIA has executed changes to the Blackwell series’ 6-layer GPU mask. Therefore, the process can now proceed without re-taping out, as production delays being minimized.

The report noted that NVIDIA’s updated version of B200 is expected to be completed by late October, allowing the GB200 to enter mass production in December, with large-scale deliveries to ODMs expected in the first quarter of next year.

Previously, as per a report from The Information, NVIDIA’s GB200 was said to be experiencing a one-quarter delay in mass shipments. Another report from the Economic Daily News further suggested that the problem likely lies in the yield rates of advanced packaging, which mainly affected the non-reference-designed GB200 chips.

Industry sources cited by Commercial Times addressed that NVIDIA’s Blackwell chip used to be facing instability in metal layers during the HV process, which was then resolved by July.

In addition, since the issue reportedly occurred in the back-end-of-line process, a new tape-out was deemed unnecessary. Still, as CoWoS-L capacity remains a bottleneck, the advanced packaging for GB200 this year is expected to adopt  CoWoS-S.

Read more

• [News] Foxconn Confirms Shipment of NVIDIA’s GB200 to Start in Q4 as Planned
• [News] Foxconn Remains Unfazed Despite NVIDIA’s GB200 Delay, with Customers Aim to Secure Their Orders

(Photo credit: NVIDIA)

Amid the rising of emerging applications in the AI market, the booming demands for high-performance computing (HPC), high-bandwidth memory (HBM), CoWoS advanced packaging, and high-performance storage, have energized the wafer foundry industry.

Given the broader applicability of 12-inch wafer in advanced process chips, the global expansion of 12-inch wafer production has accelerated in recent years. Leading companies like TSMC, Intel, UMC, Vanguard International Semiconductor (VIS), SMIC, and Huahong have successively released production capacity.

• VIS’ Singapore 12-Inch Fab Got Approved

On September 4, VIS and NXP jointly announced the approval of their Singapore-based 12-inch wafer fab joint venture by regulatory authorities in Taiwan, Singapore, and other regions.

The joint venture, named VisionPower Semiconductor Manufacturing Company (VSMC), will begin construction of its first 12-inch (300mm) wafer fab in the second half of this year.

VIS estimates that trial production will begin in 2027, with profitability expected by 2029. TSMC will provide technological support, and the market holds a favorable long-term outlook for the company’s operations.

Upon its mass production, both companies may consider building a second fab. Currently, VIS operates five 8-inch fabs located in Taiwan and Singapore. Three of the 8-inch fabs are in Hsinchu, and one in Taoyuan. The average monthly capacity of its 8-inch fabs in 2023 was about 279,000 wafers.

• TSMC Expands Production Worldwide

On August 20, TSMC held a groundbreaking ceremony for its new German fab, ESMC, which is set to begin construction by the end of the year and aims to start production by the end of 2027.

The project involves an investment of over EUR 10 billion and is expected to have a monthly capacity of 40,000 12-inch wafers, utilizing TSMC’s 28/22nm planar CMOS and 16/12nm FinFET process technologies.

In early September, Taiwan’s Ministry of Economic Affairs announced that TSMC plans to build a third fab in Japan to produce advanced semiconductors, with construction expected after 2030.

TSMC’s first fab in Kumamoto, Japan, officially opened on February 24, 2023, and will begin mass production in Q4 this year using 28/22nm and 16/12nm process technologies, with a monthly capacity of 55,000 wafers.

The second fab in Kumamoto is planned, with construction expected to start by the end of this year and operations to begin by the end of 2027, targeting 6/7nm nodes.

Additionally, TSMC’s 2nm fabs in Hsinchu (Fab 20) and Kaohsiung (Fab 22) in Taiwan are scheduled to start mass production next year.

In the U.S., TSMC’s first fab in Arizona is scheduled to begin producing chips using 4nm technology in the first half of 2025. The second fab will produce both 3nm and 2nm chips using next-generation nanosheet transistors, with production starting in 2025.

Plans for a third fab are also underway, with production of chips using 2nm or more advanced processes expected to begin in 2028.

• UMC’s Fab 12i in Singapore has Set Equipment in Place

On May 21, UMC held a ceremony for the settlement of equipment at its expanded Fab 12i in Singapore with the arrival of the first equipment.

UMC has operated 12-inch fabs in Singapore for over 20 years, and in February 2022, it announced the plan to invest USD 5 billion to expand Fab 12i, adding a new 12-inch fab with a monthly capacity of 30,000 wafers, focusing on 22/28nm processes. Mass production is expected by early 2026.

• Toshiba’s 12-Inch Wafer Fab Completed

On May 23, Toshiba Electronic Devices & Memory Corporation announced the completion of its new 300mm power semiconductor manufacturing fab, with a total investment of JPY 100 billion and plans to begin production in March 2025.

The fab will be built in two phases, with the first phase starting production within the 2024 fiscal year. Once fully operational, Toshiba’s power semiconductor capacity will be 2.5 times that of 2021. Equipment installation is underway, with mass production expected in the second half of FY2024.

• Powerchip Begins Construction of Two New 12-Inch Fabs

On March 13, Powerchip held a groundbreaking ceremony for a 12-inch wafer fab in partnership with India’s Tata Group, located in Dholera, Gujarat, with a total investment of INR 910 billion rupees (about USD 11 billion).

The fab will have a monthly capacity of 50,000 wafers and will produce chips using 28nm, 40nm, 55nm, 90nm, and 110nm nodes.

In early May, Powerchip also announced plans for a new 12-inch fab to expand advanced packaging capacity to support growing demand for AI devices. Powerchip’s chairman stated that the company will provide interposers, one of the three components in CoWoS packaging technology.

• Texas Instruments Built Three New 12-Inch Fabs

Texas Instruments is currently expanding its 300mm capacity to meet future demand for analog and embedded processing chips. TI plans to invest USD 30 billion in building up to four interconnected fabs (SM1, SM2, SM3, SM4) in the coming decades.

According to its 2022 roadmap, TI will build six 300mm fabs by 2030, with RFAB2 in Richardson, Texas, and LFAB (acquired from Micron) already starting production in 2022 and 2023, respectively. Two of the Sherman fabs were completed in 2023, with two more planned for 2026-2030.

In addition to the plan mentioned above, TI also announced the plan for a second 300mm fab in Lehi, Utah in February 2023, adjacent to its existing 12-inch fab, with production estimated to begin in 2026, focusing on producing analog and embedded processing chips. These fabs will be combined into one once the construction is completed.

On August 16, Texas Instruments announced that it received USD 1.6 billion in funding from the U.S. CHIPS Act. This funding will be used to build a cleanroom for the SM1 fab and complete the pilot production line, construct a cleanroom for LFAB2 to begin initial production, and build the shell for the SM2 fab.

• Intel Focuses on U.S. Projects in Arizona and Ohio

Intel has disclosed chip expansion plans in multiple regions, including Arizona, New Mexico, Ohio, Oregon, Ireland, Israel, Magdeburg, Malaysia, and Poland. However, due to market challenges and poor financial results, some of Intel’s expansion plans have been delayed.

Currently, Intel is advancing the construction of large semiconductor manufacturing plants in Arizona and Ohio for the production of cutting-edge semiconductors, as well as working on equipment development and advanced packaging projects at smaller facilities in Oregon and New Mexico.

• GlobalFoundries Revved up Investment in the U.S. and Portugal

On February 19, the U.S. government announced a USD 1.5 billion subsidy for GlobalFoundries. According to a preliminary agreement with the U.S. Department of Commerce, GlobalFoundries will establish a new semiconductor manufacturing facility in Malta, New York, and expand its existing Fab 8 plant in the same location.

The facility will leverage manufacturing technology already implemented in GlobalFoundries’ plants in Germany and Singapore to produce automotive chips, effectively introducing mature-node technology into Fab 8.

In February of this year, GlobalFoundries also announced a partnership with Amkor Technology to build a large packaging facility in Portugal.

It plans to transfer the 12-inch wafer-level packaging production line from its Dresden plant to Amkor’s facility in Porto, Portugal, aiming to establish Europe’s first large-scale backend facility. GlobalFoundries will retain ownership of the tools, processes, and IP transferred to Porto.

• China’s 12-Inch Wafer Production Lines Entered New Stages

In China, companies like SMIC, Huahong, CR Micro (Shenzhen), and Zensemi (Guangzhou) are making new progresses in 12-inch wafer production.

SMIC expects its monthly 12-inch wafer capacity to increase by 60,000 by the end of the year.

Huahong is speeding up the construction of its new 12-inch fab in Wuxi, with the first lithography machine installed on August 22, aiming for production in 1Q24.

CR Micro’s 12-inch fab in Shenzhen has entered the stage of equipment installation and debugging, with production expected to start in late 2024.

Zensemi’s 12-inch wafer manufacturing production line has went into production.

Read more

• [News] Wafer Foundry Market Shows Signs of Recovery
• [News] Two Contrasting Trends Emerge in Wafer Foundry Industry

(Photo credit: TSMC)

Jun He, Vice President of Advanced Packaging Technology and Service at TSMC, stated that 3D IC is a crucial method for integrating AI chip memory with logic chips.

According to a report from TechNews, regarding the development of 2.5D CoWoS advanced packaging, which integrates eight chiplets, TSMC will use the A16 advanced process to manufacture the chiplets, and integrated them with 12 HBM4, which is expected to be launched in 2027.

Reportedly, in his speech at the Semicon Taiwan 2024 “3D IC / CoWoS for AI Summit,”  He noted that the global semiconductor market is projected to become a trillion-dollar industry by 2030, with HPC and AI being the key drivers, accounting for 40% of the market, which also make AI chips crucial drivers for 3D IC packaging.

The reasons customers choose to manufacture AI chips with 3D IC platform for multi-chiplet design would be related to their lower costs and reduced design transition burdens.

Jun He explained that by converting a traditional SoC+HBM design to a chiplet and HBM architecture, the new logic chip would be the only component that needed to be designed from scratch, while other components such as I/O and SoC can use existing process technologies. This approach reduces mass production costs by up to 76%.

Although the new architecture might increase production costs by 2%, the total cost of ownership (TCO) is improved by 22% due to these efficiencies, He noted.

However, 3D IC still faces challenges, particularly in increasing production capacity. Jun He emphasized that the key to enhancing 3D IC capacity lies in the size of the chips and the complexity of the manufacturing process.

Regarding chip size, larger chips can accommodate more chiplets, improving performance. However, this also increases the complexity of the process, which can be three times more challenging. Additionally, there are risks associated with chip misalignment, breakage, and failure during extraction.

To address these risk challenges, Jun He identified three key factors: tool automation and standardization, process control and quality, and the support of the 3DFabric manufacturing platform.

For tool automation and standardization, TSMC’s differentiated capabilities with its tool suppliers are crucial. With 64 suppliers now involved, TSMC has gained the ability to lead in advanced packaging tools.

In terms of process control and quality, TSMC utilizes high-resolution PnP tools and AI-driven quality control to ensure comprehensive and robust quality management. Finally, the 3DFabric manufacturing platform integrates 1,500 types of materials within the supply chain to achieve optimization.
